ROLLING SHUTTER OPERATOR
Model No: AZRSDC400/AZRSDC600/AZRSDC800
The operator is easy to install and maintain, offering powerful, quiet, and energy-efficient performance. With a built-in UPS system and automatic charging, it ensures up to 20 operations during power failure using 4.5Ah 24V batteries.
Easy to install and maintain provided with long life.
Poweul, Less noise, less energy consumption.
Operator comes with resistance rebound function
Works with UPS control system.
In case of power failure, the UPS automatic power reserves, that can ensure motor run about 20 times in normal.
The UPS control system gets charged automatically.
Reserve power supply is used in baeries for universal product(4.5Ahl 24V).
|
MODEL
|
INPUT VOLTAGE & FREQUENCY
|
RATED CURRENT
|
POWER (W)
|
OUTPUT TORQUE (n.m)
|
MAX LIFTING FORCE (Kg)
|
OUTPUT SPEED (RPM)
|
MAX RAISING HEIGHT (m)
|
TUBE DIAMETER (mm)
|
WORKING TIME (Min)
|
MOTOR & BRACKET WEIGHT (Kg)
|
|---|---|---|---|---|---|---|---|---|---|---|
|
AZRSDC400
|
220 V - 240 V AC
|
10
|
200
|
168
|
400
|
4.6
|
4.5
|
100
|
5
|
M 15 / B 12.7
|
|
AZRSDC600
|
220 V - 240 V AC
|
14
|
240
|
412
|
600
|
4.2
|
6
|
150
|
5
|
M 15.3 / B 14.5
|
|
AZRSDC800
|
220 V - 240 V AC
|
18
|
380
|
647
|
800
|
3.9
|
9
|
150
|
5
|
M 16.8 / B 18.5
|
