ITALY
ROLLING SHUTTER OPERATOR
Model No: AZ RSIT 400/ AZ RSIT 600
Lightweight and durable with a high-strength aluminum case, the motor offers low noise, long life, and fast performance. It supports multiple control modes and ensures safe operation during power failures, ideal for various commercial spaces.
Description
Light and handy, superior quality: The motor case are pressure-cast with high strength aluminum alloy.
Less noise, long cycle life: Reduction gear is made of high quality alloy, heat resistant with less noise.
High power and fast: The motor is efficiently-designed, all components are made of superior materials with minimum time and energy.
Power failure: In times of the power failure, pulling chain by hand may li the door up, and pulling the clutch lever may let the door down.
Easy operation, safety and security: There are several ways of controlling, by using remote controller, hand control, and pulling chain by hand when power is failure. And to keep from breaking in, you could also lock the hand controlling by remote controller.
Suitable for: garages, shops, malls, exhibition halls, museums, factories, warehouses and etc.
|
TECHNICAL SPECIFICATIONS
|
AZ RSIT 400
|
AZ RSIT 600
|
|---|---|---|
|
Input Power
|
220 V - 240 V AC
|
220 V - 240 V AC
|
|
Rated Power
|
300 W
|
370 W
|
|
Max. Torque
|
343 Nm
|
412 Nm
|
|
Output Speed
|
5.5 RPM
|
5.5 RPM
|
|
Lifting Force
|
400 Kg
|
600 Kg
|
|
Working Time
|
7 - 8 mins
|
7 - 8 mins
|
|
Tube Diameter
|
100 mm
|
100 mm
|
|
Protection Class
|
IP 44
|
IP 44
|
|
Motor Weight
|
14 Kg
|
14.5 Kg
|
|
Bracket Weight
|
12.7 Kg
|
14.5 Kg
|
