ROLLING SHUTTER OPERATOR
Model No: AZRSFR300/AZRSFR600/AZRSFR800/AZRSFR1000/AZRSFR1300/AZRSFR1500
Crafted from high-strength aluminum alloy, the motor ensures efficient, low-noise, and long-lasting performance. It supports remote and manual control with enhanced security, suitable for garages, malls, and industrial spaces.
- ✔ The AUTOZON fire-rated rolling shutter operator is specially designed for fire shutters.
- ✔ Compact design, powerful drives, and safe and reliable performance.
- ✔ The control box can be connected to any fire or smoke detection system or equipped with standalone smoke detectors.
- ✔ An inbuilt thermal fusible link option is available.
- ✔ Stable and reliable braking with accurate limit positioning and double limit-switch protection.
- ✔ Automatic closing during fire incidents and manual operation during power failures.
| Model | Voltage | Power (W) | Lifting Power (Kg) | Output Torque (N.m) | Output Speed (R/Min) | Lifting Height (M) | Standard Tube Diameter (Mm) | Motor & Bracket Weight (Kg) |
|---|---|---|---|---|---|---|---|---|
| AZRSFR300 | 380 V – 420 V AC | 180 | 300 | 168 | 6.5 | 6 | 100 | M 11.8 / B 14.6 |
| AZRSFR600 | 380 V – 420 V AC | 250 | 600 | 420 | 6.5 | 6 | 150 | M 12.4 / B 14.6 |
| AZRSFR800 | 380 V – 420 V AC | 550 | 800 | 647 | 4.8 | 9 | 150 | M 16.1 / B 19 |
| AZRSFR1000 | 380 V – 420 V AC | 550 | 1000 | 809 | 4.4 | 9 | 150 | M 16.4 / B 26.4 |
| AZRSFR1300 | 380 V – 420 V AC | 600 | 1300 | 1401 | 5.2 | 9 | 200 | M 23.2 / B 30.3 |
| AZRSFR1500 | 380 V – 420 V AC | 800 | 1500 | 1617 | 4.8 | 9 | 200 | M 24.5 / B 39.5 |
