SWING DOOR OPERATOR
Model No: AZSWD202C
The Swing Door Operator offers low-noise operation with enhanced safety and reliability. Its transformer-less design supports a wide range of power supply voltages and provides interfaces for sensors, access control, magnetic locks, and backup batteries. It features an interlocking function between doors and reverses direction upon detecting obstacles. Ideal for offices, storefronts, banks, factories, restaurants, hotels, shopping centers, hospitals, and more, it ensures convenience and advanced functionality for various applications.
Description
The Swing Door Operator drive unit operates with less noise, with reliable performance and safety, providing more convenience
The Swing Door Operator is a new upgraded transformer-less drive that offers a wider range of supply power voltages. Provides interfaces such as sensors, access control, and is equipped with interfaces for magnetic electric lock and backup battery too.
Both can realize Interlocking function between doors.
If touch obstacles or personnel in operation are encountered, the door will open in the opposite direction.
Applicable to office buildings, storefronts, banks, factories, restaurants, hotels, shopping centres, laboratories, hospitals and other places
|
Technical Specification
|
AZSWD202C
|
|---|---|
|
Door type
|
Single Door
|
|
Carrying weight
|
≤1 × 200 kg
|
|
Applicable door width
|
≤ 1200 mm
|
|
Power supply voltage
|
220 V - 240 V AC
|
|
Motor Power
|
24 V BL DC / 55 W
|
|
Opening & Closing time (Speed)
|
3 - 7 s (adjustable)
|
|
Open time
|
1-30 s (adjustable)
|
|
Open angle
|
≤ 115°
|
|
Protection level
|
IP 12
|
|
Working temperature
|
-20 ~ + 50°C
|
|
Product size (unit)
|
518 x 81 x 115 mm
|
|
Product weight (unit)
|
10 Kg
|
