GUARD
Bollard
Model No: AZBH220
AUTOZON hydraulic retractable bollards offer high-security access control with a compact design for continuous, heavy-duty use. Their sleek aesthetics enhance the environment while ensuring 100% reliable protection.
Description
AUTOZON hydraulic retractable bollards are designed for high security vehicle entrances, military, industrial, governmental
and commercial buildings.
Hydraulic rising bollard to protect access roads or any sensitive area 100%.
Duty Rated hydraulic Rising Bo lards: designed for continuous and frequent use.
Compact version with incorporated hydraulic device for easy insta lation, with hydraulic fast connections Integrated
foundation box and vehicle manhole cover.
The bollards pleasing aesthetics enhance the look of the area, a non-stop duty cycle ensures lasting performance.
|
Technical Specification
|
AZBH220
|
|---|---|
|
Product dimension
|
500mm*380mm*800(Down position). 500mm*380mm*1400mm(Up position)
|
|
Cylinder material
|
304 stainless steel.
|
|
Cylinder diameter
|
219mm
|
|
Cylinder intercept height
|
600mm
|
|
Cylinder thickness
|
6mm, other options are available
|
|
Working voltage
|
380VAC, 50/60HZ
|
|
Rated power
|
200W
|
|
Working speed
(High speed / Low Speed)
|
3-5s
|
|
Working cycle
|
Intensive - 3000 cycle/day
|
|
Emergency down function
during power fails
|
Yes
|
|
Cylinder treatment
|
BRUSHED STAINLESS STEEL
|
|
Drive unit
|
LCN20T
|
|
Impact resistance
|
25000 Joules
|
|
Breakout resistance
|
300000 Joules
|
|
Security level
|
IP68
|
|
Working temperature
|
-40°C~+70°C
|
|
Total weight
|
85kg
|
