HULK
Sliding Gate Operator
Model No: AZSL605I/ AZSL606I
The AZSL605I / AZSL606I Industrial Sliding Gate Operator is built for heavy industrial and commercial gates, ensuring reliable automation. Its robust design and high-performance gear motor provide powerful and smooth operation. Designed for durability, it guarantees long-lasting efficiency and security.
Description
Industrial sliding gate operator is designed to move gates installed in heavy industrial and commercial buildings
Reliable and robust operator with high-performance gear motor
Powder coated steel vandal-proof box with additional fan ventilation & foundation plate.
It has non – stop operative capacity 24/7 & long lasting operator with zero maintenance.
Easily accessible emergency release
Suitable for industrial & commercial purpose etc.,
|
Technical Specification
|
AZSL605I
|
AZSL606I
|
|---|---|---|
|
Power supply
|
220V - 240V AC
|
220V - 240V AC
|
|
Motor power Supply
|
380V AC / 50Hz
|
380V AC / 50Hz
|
|
Motor power
|
2200 W
|
3000 W
|
|
Maximum weight of gate
|
5000 Kg
|
6000 Kg
|
|
Maximum Current
|
9.6 A
|
12 A
|
|
Output Torque
|
14.7 Nm
|
19.8 Nm
|
|
Lubrication
|
Oil
|
Oil
|
|
Working Duty
|
S4, 24/7
|
S4, 24/7
|
|
Gate Moving Speed
|
12m / min
|
12m / min
|
|
Working temperature
|
-35°C ~ + 65°C
|
-35°C ~ + 65°C
|
|
Protection Class
|
IP 54
|
IP 54
|
|
Product Weight
|
75
|
75
|
|
Rack Module
|
M6
|
M6
|
